Test Parameters

PT, APTT，FIB，TT，DD，AT，FDP，ACT，Anti-Xa，ect.

Sample Types

Whole blood, plasma

Reagent Type

Lyophilized reagent

Test Time

≦12min

Barcode Recognition

Automatic identification of two-dimensional code for reagent disc

Printer

Built-in thermal printer, also available to external printer (with wireless printer drive)

Operating System

Android 5-inch (Version 5.1), distinguishability 720×1280, support LIS/HIS system

Size

270mm*180mm*155mm

Weight

≦3kg

Test Principle

Photoelectric colorimetry

Sample Types

Whole blood, plasma, serum

Test Time

15min

Barcode Recognition

Automatic identification of two-dimensional code for reagent disc

Reaction Temperature

37±0.5℃

Data Interface

USB, LAN

Printer

Built-in thermal printer

Supply Voltage

AC1100V-240V, 50-60Hz

Operating system

Android, supporting LIS/HIS

Memory Storage

Size

210mm*250mm*310mm

Weight

10kg

Test Principle

Optical solidification method、colored substrate method、immunoturbidimetry

Test Parameters

PT, APTT，FIB，TT，DD，AT，FDP，ACT，Anti-Xa，ect.

Sample Types

Whole blood, plasma

Reagent Position

20

Test Position

36

Reaction Temperature

37±0.5℃

Test Speed

PT≥210Ts/h

Light Source

LED，with multiple wavelength detection

Communication

Direct external printer，LIS system，with user-defined report

Operating System

Android system with visual operating interface

Calibration System

Automatic multi-point calibration with intelligent calibration curve generation and manual calibration

Barcode Recognition

Support reagent, disc (reaction cuvette), sample scanning (optional)

Data Storage

Solidification reaction curve with storage display, >10000 tests

Data Interface

2 USB interfaces, 1 RS232 serial port and 1 LAN interface

Size

270mm*180mm*155mm

Test Principle

Coagulation method, immunoturbidimetry

Test Parameters

PT, APTT，FIB，TT，DD

Sample Types

Peripheral venous blood

Sample Position

12

Test Capacity

24/30/36 positions

Test Speed

≥180T/H

Reagent Storage

2-8℃

Reaction Temperature

37±1℃

Operating System

Android system

Size

490mm*440mm*590mm

Output Mode

External printer, LIS system

Test Principle

Magnetism particulate immuno chemistry luminescence method

Test Parameters

PCT, IL-6, BNP, NT-_proBNP, cTnl, MYO, CK-MB, PGI/II, G17

Sample Types

Peripheral venous blood，plasma, serum

Sample Position

12

Reagent Position

5

Test Capacity

12 positions

Reagent Storage

2-8°C

Reaction Temperature

37±0.5℃

Size

480mm*470mm*590mm

Output Mode

External printer, LIS system

Test Principle

Photoelectric colorimetry

Sample Types

Anticoagulant whole blood, plasma, serum

Transmission Interface

On-line use of LIS system

Barcode Recognition

Automatic identification of two-dimensional code for reagent disc

Reaction Temperature

37±0.5℃

Light Source

LED

Printer

Built-in thermal printer, also available to external printer (with wireless printer drive)

Operating System

Android 5.1（5 inches）

Memory Capacity

1GB, with expandable 32GB TF card

Size

270mm*180mm*155mm

Weight

3kg
